Tiantai 1000L/h Membrane filter

I.Application and Features

This machine is widely used for the filtration of beer, yellow wine, fruit juice beverages, pharmaceuticals, and other liquids. The device adopts advanced foreign microporous membrane filtration technology, offering excellent clarification and sterilization filtration performance. Depending on the material to be filtered, different filter cartridges (membranes) can be selected. This allows the desired molecules to pass through the membrane for purification, while impurities and bacteria in the material are retained.

II.Features:

Compact size, low investment, easy to transport and install

Hygienic design with fully enclosed ope5tion, no sanitary dead corners

Filter cartridges are easy to install and remove, resistant to mold, and leak-proof

Capable of meeting any flow rate requirements

No residual waste

III Specification

IV Brief Description of the Process Flow:

The standard setup consists of the following filters: one pre-filter and one fine filter.

Pre-Filter:
Used to trap diatomaceous earth or other solid particles in the filtered liquid, thereby protecting the fine filter. The filtration precision is 1μm.
The pre-filter serves two important functions:

1.To retain yeast and impurities that would normally pass through during filtration.

2.To reduce the load on the fine filter and extend the service life of its filter cartridge.

Fine Filter:
Removes particles, microorganisms, and flocs to further enhance the clarity and brightness of the beer. The filtration precision is 0.45μm.
To reduce operator workload and facilitate equipment disassembly, a quick-opening design is considered.

V.Equipment Composition:

a.One pre-filter and one fine filter are installed on a single base frame.
b. Piping and valves are made of 304 stainless steel.
c. CIP and backflushing pipelines use Φ32 clamp-type butterfly valves.
d. Equipped with pressure gauges, drain valves, and other necessary valves.
