2000L Micro Beer Brewery Equipment is designed for medium to large-scale breweries seeking consistent quality, efficient production, and flexible brewing capabilities.
2000L three vessel brewhouse includes mash tun, lauter tun, kettle/whirlpool tun, for 1 to 3 batches brewing per day.
Fermentation vessels can be 2000L, 4000L, or 6000L to accommodate various beer styles with different fermentation cycles.
A fully functional setup includes:Automatic control system,Malt milling system,CIP (Clean-in-Place) system,Glycol cooling system,Steam heating system,Compressed air system,RO water supply system
| Capacity / batch | 2000L | 2000L | 2000L |
| Brewing batch / day | 1 | 2 | 3 |
| Brewhouse specification | 2 vessels | 3 vessels | 4 vessels |
| Fermenters specification | 2000L*10 | 4000L*10 2000L*2 | 6000L*10 4000L*2 |
Layout and Process
Tiantai designs the layout according to your site and conducts beer process design to improve site utilization and save energy for you.
Pallets *8-10 sets
Dry mills *1 unit
- Mash tun *1 unit
- Lauter tun *1 unit
- Brew kettle *1 unit
- Whirlpool tank *1 unit
- Plate and frame heat exchanger *1 unit
- Wort aeration system *1 set
- Yeast pitching system *1 set
- Supporting pumps, valves, sanitary stainless steel pipes, various sensors, operating platforms, etc.
- 20HL fermenter *12 units
- 40HL fermenter *14 units
- Supporting pumps, valves, sanitary stainless steel pipes, various sensors, operating platforms, etc.
– Kieselguhr adding tank *1 unit
– Front buffer tank *1 unit
– Kieselguhr mixing tank *1 unit
– Candle filter *1 unit
– Rear buffer tank *1 unit
– Bag trap *1 unit
– Other adding systems are equipped according to the process
– Supporting pumps, valves, sanitary stainless steel pipes, various sensors, operating platforms, etc.
– 40HL bright beer tank *1 unit
– Supporting pumps, valves, sanitary stainless steel pipes, various sensors, operating platforms, etc.
– Flash pasteurizer *1 unit
– Buffer tank *1 unit
– Supporting pumps, valves, sanitary stainless steel pipes, various sensors, operating platforms, etc.
PLC cabinet *1 set
– Hot alkali tank *1 unit
– Hot water tank (sterile water tank) *1 unit
– Supporting pumps, valves, sanitary stainless steel pipes, various sensors, etc.
– Hot liquor tank *1unit
– Supporting pumps, valves, sanitary stainless steel pipes, various sensors, etc.
– Cold liquor tank *1 unit
– Supporting pumps, valves, sanitary stainless steel pipes, various sensors, etc.
– Brewing water tank *1 unit
– Supporting pumps, valves, sanitary stainless steel pipes, various sensors, etc.
– Chiller *1 unit
– Glycol water tank *1 unit
– Supporting pumps, valves, sanitary stainless steel pipes, various sensors, etc.
– Raw water tank *1 unit
– RO water treatment machine *1 unit
– Supporting pumps, valves, sanitary stainless steel pipes, various sensors, etc.
– Steam boiler *1 unit
– Distributor *several set
– Steam pipes, valves, etc
– Oil-free air compressors *2 sets
– Air buffer tank *1 sets
– Air dryer *1 sets
– Several filters
– Supporting pumps, valves, etc.
– Power cables
– Signal communication cables
– Cable bridge
– Bridge bracket
– Conduit
– Depalletizer *1 set
– Rinsing machine *1 unit
– Filling machine *1 unit
– Capper machine *1 unit
– Tunnel pasteurizer *1 unit
– Drying Machine *1 unit
– Labelling Machine *1 unit
– Inspection Machine *1 unit
– Packaging Line *1 set
– Palletizer *1 set
Brewhouse
- 2000L three vessel brewhouse: mash tun + lauter tun + kettle/whirlpool tun
- Hot water tank and cold water tank for brewing water supply
- Sanitary welded thermowell for high accuracy temperature sensor
- Brewhouse tanks insulation layer is aluminum silicate fiber for excellent heat resistance
- Overall acid washing and passivation, inside polishing to 0.2~0.4μm with no dead corner
- Glass hydrator with pneumatic flat valve for auto malt feeding
- Auto lifted grain rake and dozer for easy spent grain discharging
- Wort collection ring and back pressure flushing device at bottom
- Inner heater calandria in kettle tun, increase heat exchange area, ensure efficient mixing.
- Whirlpool tun tangential inlet pipe bend radius ≥200mm, less resistance, 3-5m/s entrance velocity
Fermentation System
- Wort fermentation or maturation
- 100% TIG welding with pure argon gas shield
- Interior Finish: Sanitary 2B finish, Pickled and Passivated
- Exterior Finish: Oil brushed finish
- Interior full polished to 0.2~0.4 μm without dead corner
- Insulation: TH=100mm with low thermal conductivity PU
- Cooling Jacket: Dimple plate on bottom and side wall, welded without over burning
- Tank Working Pressure: ≦ 2bar/30psi
- Top mounted double clamp 360° rotary CIP spraying ball and port, 1pc
- Mechanical safe valve PVRV 2bar/30psi on top
- Full sanitary sampling valve with EPDM seal
- Hydraulic shock pressure gauge on CIP arm
- Horizontal mounted rotating racking arm with butterfly valve
- Discharge arm with butterfly valve, removable and easy to clean
- Dry hopping port 4” with solid end cap
Filling and Packaging System
- Depalletizer
- Rinsing machine
- Filling machine
- Capping machine
- Tunnel pasteurizer or flash pasteurizer
- Drying machine
- Labeling machine
- Date printer machine
- Level detection machine
- Automatic carton packing machine
- Carton date printer machine
- Automatic PE film shrink packing machine
- Palletizer
- Belt conveyor
Packaged Style | Size | Capacity |
Glass Bottles | 330ml / 500ml | 1000-2000 bottles/hour |
Cans | 330ml / 500ml | 1000-2000 cans/hour |
Beer Kegs | 20L / 30L / 50L | 60–100 kegs/hour |
PET Bottles | 500ml / 1L | 1000-2000 bottles/hour |
The packaging line can be configured as a mixed production line of single or multiple packaging formats according to product strategy | ||
Automation
- SIEMENS S7-1200/S7-1500 program and touch screen
- Automatic water mixing station
- Automatic wort cooling station
- Mashing stage temperature control and curve storage
- Recipe data storage procedure
- Pressure transmitter for liquid level monitoring
- Proximity switch on the manhole
- Empty level sensor to protect the wort pump
- Foam sensor to control the boiling process
- Automatic rising-lowering rake in the lauter tun
- Pressurized dynamic boiling in the kettle tun
